1.1 Ton KV13 Mini Excavator with Diesel Engine
$13,172,993.00
| Specification | Dimensions (mm) | ||
|---|---|---|---|
| Engine Model | Huaruipu 192 | Overall length | 2400 |
| Type | Single-cylinder | Overall height (to top of boom) | 2230 |
| Displacement (L) | 0.498 | Overall width | 1100 |
| Rated Power (kw/rpm) | 8.8-10.3/3600 | Tail swing radius | 1635 |
| Type | Dual-pump | Track total length (mm) | 1050 |
| Machine weight (kg) | 1000 | Max. digging height | 2545 |
| Bucket capacity (㎥) | 0.03 | Max. dumping height | 1708 |
| Track width (mm) | 923 | Max. digging depth | 1735 |
| Working device type | Backhoe | Max. digging radius on ground | 3084 |
| Bucket outer width (m³) | 375 | Max. lifting height of bulldozer | 142 |
| Size (mm) | 2400*1100*2230 | Max. cutting depth of bulldozer | 315 |
| Motor | Eaton travel motor | Chassis | Telescopic chassis |
| Roof | Standard two-leg roof | Multi-way Valve | Load sensing valve |
